MLSysOps Plugin System🔗

The MLSysOps framework provides a structured plugin mechanism that enables a modular approach to integrating configuration decision logic with arbitrary mechanisms. Plugins are categorized into two types: core and custom. Core plugins are always enabled and are used by MLSysOps to perform essential management functions. In contrast, custom plugins can be configured and activated either during installation or at runtime, allowing flexibility and extensibility based on system requirements.

Core plugins provide essential policies and mechanisms. The following table briefly describes the initial plugins that have been developed, up to the time of writing of this document

Execution Flow🔗

Figure X illustrates the execution flow of the MAPE tasks and the integration of both policy and mechanism plugins. The Monitor task runs periodically at all times, regardless of whether an application has been submitted, collecting telemetry data and updating the local state. When a new application is submitted to the system, a separate Analyze task thread is launched, which uses the analyze method of the corresponding policy plugin. Based on the result, the analysis session either terminates or triggers a background Plan task.

The Plan task then invokes the policy plugin’s plan method to generate a new configuration plan. If a valid plan is produced, it is pushed into a FIFO queue. The Plan Scheduler periodically processes the plans in the queue and initiates an Execute task for each mechanism included in the output of the policy plugin’s plan method. The Plan Scheduler enforces a constraint that prevents two different plans from applying configuration changes to the same mechanism within the same scheduling cycle.

Finally, the Execute task for each mechanism calls the apply method of the corresponding mechanism plugin. The results of the configuration are made visible to the next execution of the Analyze task, either via direct status retrieval or through the telemetry stream.
