System Description

The infrastructure descriptions must be provided during the agent installation process. Taking the example of a Node description registration, it is propagated to the framework using a Bottom-Up approach, in contrast to the application registration solution (Top-Down), as shown in Figure 43. To this end, we follow the usual node registration protocols, e.g., node registration to a Kubernetes cluster. In our case, the Node agent sends the respective description to the Cluster agent, which transforms it into a Custom Resource and applies it to Kubernetes. In addition, the Cluster agent updates the Cluster formal description (also defined as a Custom Resource) with high-level information that can be used by the Continuum agent in order to perform filtering based on the available sensors, accelerators, and node types (e.g., to meet any relevant application deployment constraints). Finally, the Cluster agent notifies the Continuum agent, via the agent protocol, so that the latter can update its Cluster-related structures.
